The Elation 3-stage wireguided balloon dilator features the premium quality found in all Elation balloons while providing a guidewire to help manage strictures with difficult access.
Video Gallery
Elation Balloon Dilator: Comparison Video
Elation Balloon Dilator [In-Service]
Features & Benefits
Complete Deflation & Easy Removal
Proprietary balloon and catheter designs result in a rapid, complete deflation and easy removal from the scope and includes an ultra stiff guidewire.
Radiopaque Marker Bands
Radiopaque marker bands positioned at the balloon shoulders for precise dilation location
High Clarity Material
High clarity material provides an optimal optical clarity without cone distortion
Low Reinsertion Force
Low re-insertion force allows the balloon to pass through the working channel of the scope more than one time
Easy Containment
Simple locking clip allows for easy containment of the catheter when not in use
Printed Marker Bands
Printed marker bands on the catheter provides a means in which to measure the length of the stricture
Documents
Discover more about the Elation® 3-Stage Wireguided Dilation Balloon by reviewing the brochures and Instructions for Use.
Current IFUs
Current Brochures
Order Information
View All Details
| Catalog Number | Minimum Required Working Channel | Recommended Guide Wire | Balloon Outer Diameters | Balloon Length (mm) | Catheter Length (mm) | French Size | Sterilization | Latex Free | Shipping Box Qty |
|---|---|---|---|---|---|---|---|---|---|
| EB18 | 2.8 mm | 0.035" (0.89 mm) | 18 mm, 19 mm, 20 mm | 55 mm | 1800 mm | 7.5F | ETO | Yes | 20 |
| ECB18 | 2.8 mm | 0.035" (0.89 mm) | 18 mm, 19 mm, 20 mm | 55 mm | 2400 mm | 7.5F | ETO | Yes | 20 |
| EPB10 | 2.8 mm | 0.035" (0.89 mm) | 10 mm, 11 mm, 12 mm | 55 mm | 1800 mm | 7.5F | ETO | Yes | 20 |
| EPB12 | 2.8 mm | 0.035" (0.89 mm) | 12 mm, 13.5 mm, 15 mm | 55 mm | 1800 mm | 7.5F | ETO | Yes | 20 |
| EPB15 | 2.8 mm | 0.035" (0.89 mm) | 15 mm, 16.5 mm, 18 mm | 55 mm | 1800 mm | 7.5F | ETO | Yes | 20 |
| EPB6 | 2.8 mm | 0.035" (0.89 mm) | 6 mm, 7 mm, 8 mm | 55 mm | 1800 mm | 7.5F | ETO | Yes | 20 |
| EPB8 | 2.8 mm | 0.035" (0.89 mm) | 8 mm, 9 mm, 10 mm | 55 mm | 1800 mm | 7.5F | ETO | Yes | 20 |
| EPCB10 | 2.8 mm | 0.035" (0.89 mm) | 10 mm, 11 mm, 12 mm | 55 mm | 2400 mm | 7.5F | ETO | Yes | 20 |
| EPCB12 | 2.8 mm | 0.035" (0.89 mm) | 12 mm, 13.5 mm, 15 mm | 55 mm | 2400 mm | 7.5F | ETO | Yes | 20 |
| EPCB15 | 2.8 mm | 0.035" (0.89 mm) | 15 mm, 16.5 mm, 18 mm | 55 mm | 2400 mm | 7.5F | ETO | Yes | 20 |
| EPCB6 | 2.8 mm | 0.035" (0.89 mm) | 6 mm, 7 mm, 8 mm | 55 mm | 2400 mm | 7.5F | ETO | Yes | 20 |
| EPCB8 | 2.8 mm | 0.035" (0.89 mm) | 8 mm, 9 mm, 10 mm | 55 mm | 2400 mm | 7.5F | ETO | Yes | 20 |
